Now that members have made a bunch of fused glass cabochons this week, what can we do with them? You can make several cabochons and mount them on your own Medieval style gemstone covered book, hot glue it onto your stapler at work and really establish that one is yours, make some really shiny refrigerator magnets but jewelry is the most common application.
I encased my cabochon in a mount by free form hand weaving seed beads. This piece used different stitches and a strong nylon mono-filament thread. The beads are 11/0 size Czech glass and 15/0 size Japanese Miyuki glass. I encased the whole cabochon because the back of the fused glass was rough and uneven.
Other methods to make jewelry with a cabochon with an irregular shape are:
You can stitch bead embroidery around the cabochon securing it onto a backing of leather or heavy fabric. This will be similar to my example but simpler in its execution.
Glue on a bar pin back to wear it as a pin.
Glue on a bail to wear it on a chain or cord. There are many colors, sizes and shapes of ready made jewelry bails.
Wire wrap the cabochon with jewelry wire.
Given the resources we have at the space, someone could even 3D print a setting for their piece and then cast it in metal!
by shellie posted in art Comments Off on How to Wear a Cabochon with an Irregular Shape
Samuel and Sylvia Sion brought in to last night’s member meeting an amazing impromptu class on fused glass. Glass usually has melting points higher than metal, yet there are these new miniature kilns that work inside of a conventional microwave oven! This makes fused glass work far more accessible and affordable from past days of using a larger plug-in electric kiln for hours. The time to melt an art glass cabochon was usually under five minutes with about 45 minutes needed for cooling. The larger kiln fit several pieces at once.
The microwave being used for glass fusing needs to be dedicated to art use only and never used for food again. (Cadmium and other pigments used for colorants are toxic, so this is a needed safety precaution.) Care needs to be taken to not overheat the microwave and destroy it, so letting the door stand open and the unit cool off between rounds of fusing glass is needed. Also, microwave kiln shelf paper needs to be placed on the base of the kiln to keep glass from melting onto the surface the kiln and destroying it. Heavy weight welding gloves worked as oven mitts to transfer hot kilns and the kilns rested safely on our ceramic fire bricks to cool.
Glass specifically made for fusing needs to be used for projects, like the brightly colored Dichroic glass example I made below. Dichroic and fusing glasses are the shiny, beautiful art glass pieces you always see in jewelry at art fairs. The price for making them yourself is very reasonable with this new method; you can buy enough to make several pieces for $20-$30. The kilns and tools to get started are being added to the small metals area and will be available within the following weeks.
by shellie posted in art, Class/Workshop Comments Off on The Joy of Melting Glass in a Microwave Oven
After several rounds of tasting, we headed to Brew & Grow to start on our Brown Ale. If you’ve never gone to Brew & Grow, this brew shop will have everything you need to start your own batch of beer from start to finish.
Gathering our ingredients entailed grabbing a cart with a bucket and scale attached and digging through our recipe book to catch all of our various grains needed for the mash. We also grabbed some yeast and hops pellets to finish up our collecting. Of course when you go to Brew & Grow you can sample some of their brews while you shop.
While the wort was being prepared I then decided it was grilling time!
Roll burgers into balls
Using a 75% / 25% fat mix, the beef was rolled into giant meat balls for smashing.
Smash into patties
Once the burgers are made into balls, it’s time to smash them down and evening out the edges to make solid patties that will not disintegrate or crumble on the flame. Salt, pepper, cajun seasoning were added on both sides of the burger.
Grill, flip only once and add cheese
Once the charcoal (which was started before the burgers were started) turns white, the lighter fluid should have burnt off and the grill is ready for use. Toss on the buns to toast them but pay attention or they can scorch to a crisp. Toss on the burgers with a spatula and note that the center is the hottest area so burgers are susceptible to scorching if you’re not careful.
The payoff: CHEESEBURGER!
Add condiments if necessary, and avoid shrinkage by removing the burgers before they are charred to a crisp. Grill flame can get up to 500 degrees, so watch out or you or your food may get burnt!
Back in brewing land, while the mash was settling, the kettle was loaded with water and lit to reach 190 degrees.
After letting the wort settle, it was time to separate the sugars from the grain.
In sparging we rinse the grain with hot water that is about 170 degrees, using the wrong temp can result in unwanted consequences!
After the wort is in the kettle we turn back on the turkey fryer in order to begin the sterilization process and killing off bacteria. As we mix the wort with a giant paddle, the heat coming from the turkey fryer singes everyone’s shins.
Once the wort is heated up, we then cool it down by pumping cold water through the copper coils to bring the temperature back down. Once the temperature drops, we then pump the remainder through a tube into the carboy.
Here our decision to use pellet hops cause a lot of blockages in the tubes. Using a mesh or filter bag on the pellet hops may have prevented some blockage but we were able to get most of the wort out into the carboy and did not smash it.
The ring of shame
From last Beer Church we got to this final end stage and this handle failed causing the carboy to fall and smash all over the shop floor. We were not to be tricked again and employed a harness setup to prevent any dropping.
Overall another successful Beer Church, we now have beer in progress which will be ready to be tapped soon. Next iteration will use Creeping Charlie as the bittering agent in lieu of hops so it will be interesting to see how these two beers compare when it’s time.
If you are interested in beer or brewing, make sure to stop by next month’s edition of Beer Church!
A while back I built a pair of sound-reactive LED towers which were on display a few times, at some local Chicago events.
To plug into the DJ mixer output required a relatively expensive device to get the stereo signals (with external gain control) seen by a computer running processing.org as a microphone input. Also, it was a relatively bulky affair to have yet another laptop sitting next to the mixer when the artist wasn’t using it to make the music.
Recently I discovered that starting with the 3.1 release, Processing can now run on a Raspberry Pi and has built-in ability to manipulate the GPIO ports. This blog entry highlights the release. This is exciting news as now the laptop can be replaced by a Pi 3 with a small touchscreen.
Here is a video of the light towers in action.
The towers each have 8 panels with 60 individually addressable RGB LEDs. These pictures show off more of the visual esthetic and the cutaway view reveals something of the construction. The LED strips are hidden in a channel in the wood supports which side illuminate acrylic panels (backed with just a strip of white cardboard). The acrylic is impregnated with a diffuser which reflects the edge-lit light 90 degrees to exit out of the faces of the panels. The white cardboard reflects the 1/2 of the light that would otherwise be directed inwards. The acrylic is produced by Evonik and is called Acrylite EndLighten. The towers themselves only require 110 VAC power. The data frames to control the LED strips are sent wirelessly from the processing script using an Open Pixel Control module which maps points on the processing screen into frames sent to a Fadecandy server running inside a OpenWRT Wifi device which is then physically connected to a Fadecandy board. I used TP-Link TL-MR3040 WiFi devices to run OpenWRT and added the Fadecandy server application into the img file used to reflash the WiFi devices. The Fadecandy GIT repository can be found here.
There were a lot of possible paths to follow in getting this build working the way I wanted it to be. Most of my Google searching turned up outdated examples, particularly due to the changes introduced in the 4.4 kernel with /boot/config.txt use of overlays. Adafruit had this very nice looking tutorial of how to get the touchscreen working with their version of the Jassie Raspbian os image. The inclusion of how to use FBCP was of particular interest as mirroring the HDMI output is important for displaying processing scripts with the 2D or 3D graphics libraries. Their Raspbian image was based on an older kernel and updating the os (sudo apt-get update; sudo apt-get dist-upgrade) turned out not to just work.
After much tinkering, these are the steps that worked for me. (note that I working with OSX 10.11)
$ curl https://processing.org/download/install-arm.sh | sudo sh
disable auto monitor-off
$ sudo nano /etc/lightdm/lightdm.conf
xserver-command=X -s 0 -dpms
The touchscreen should now display the 640×480 desktop scaled down to the 320×240 PiTFT screen. This makes things look less crisp but has the advantage that connecting to an external HDMI display will work and that most apps need the larger dimensions be usable. Note that many HDMI displays will not be able to handle a 320×240 HDMI signal.
FBCP stands for frame buffer copy, which rescales and mirrors the HDMI framebuffer (/dev/fb0) onto the PiTFT framebuffer (/dev/fb1)
The version of the 2.8″ PiTFT I got from Adafruit, comes with 4 buttons and I created this test Python script to demonstrate not only how to use the RPi.GPIO library, but how to manipulate the PiTFT backlight (so as to not burn-in the screen), use multi-threaded event handlers, and shutdown the os to safely disconnect the power.
I created this script as: /home/pi/pitft_buttons.py (chmod +c pitft_buttons.py to make it executable) and test by typing ./pitft_buttons.py. Note that pressing the bottom right button (#27) will ask for authentication for powering off the Pi. See below to set this script running as a service, in which case, the user will not be asked for authentication.
# example code tested with Pi 3
# Raspibian Jassie (4.4 kernel): https://www.raspberrypi.org/downloads/raspbian/
# Adafruit 2.8" Capacitive Touchscreen: https://www.adafruit.com/products/2423
# for running on startup see: https://learn.adafruit.com/running-programs-automatically-on-your-tiny-computer/systemd-writing-and-enabling-a-service
# make sure to update the ExecStart= entry in the Adafruit script after copying from the example
import RPi.GPIO as GPIO
# list of BCM channels from RPO.GPIO (printed on the Adafruit PCB next to each button)
channel_list = [17, 22, 23, 27]
backlightOn = True
# event handler to toggle the TFT backlight
backlightOn = False
backlightOn = True
# event handler to manage button presses
startTime = time.time()
while GPIO.input(channel) == GPIO.LOW:
print "Button #%d pressed for %f seconds." % (channel, time.time() - startTime)
# event handler to manage Pi shutdown
startTime = time.time()
while GPIO.input(channel) == GPIO.LOW:
if (time.time() - startTime) &amp;amp;gt; 2:
subprocess.call(['poweroff'], shell=True, stdout=subprocess.PIPE, stderr=subprocess.PIPE)
# initialize GPIO library
GPIO.setup(channel_list, GPIO.IN, pull_up_down=GPIO.PUD_UP)
backlight = GPIO.PWM(18, 1000)
print "Button #17 exits."
print "Button #22 toggles the TFT backlight."
print "Button #23 displayed the time the button is pressed."
print "!!! Pressing button #27 for at least 2 seconds, powers down the Pi !!!"
GPIO.add_event_detect(22, GPIO.FALLING, callback=toggleBacklight, bouncetime=200)
GPIO.add_event_detect(23, GPIO.FALLING, callback=buttonEvent, bouncetime=200)
GPIO.add_event_detect(27, GPIO.FALLING, callback=poweroff, bouncetime=200)
print "Exit button pressed."
# exit gracefully
To install pitft_buttons.py as a service,
# pitft_buttons service file, start a daemon on startup
# file: /etc/systemd/system/pitft_buttons.service
Description=Start PiTFT buttons daemon
ExecStart=/usr/bin/python -u /home/pi/pitft_buttons.py
Run a processing sketch from a script or from a terminal window or ssh session.
$ DISPLAY=:0 processing-java –sketch=/home/pi/HelloWorld –present
by chow posted in Programming, Projects Comments Off on Configuring Pi 3 with a TFT touchscreen and GPIO buttons
A long time ago a friend moved to Chicago and I invited her to my BBQ. When she got there, she was very confused.
“This is a cookout!” she said. Not understanding, I tried to figure out what she was talking about. Apparently in the south, BBQ’g means you take a smoker and smoke meat low and slow for long periods of time and a cookout is when you take your grill and cook some hamburgers and hot dogs.
Fast forward three years, it’s now 12:45am and it’s time to start BBQ’g. Today’s recipe is 18.5 pounds of pork shoulder otherwise known as Boston Butt.
What is Pork Shoulder?
Boston Butt / Pork Shoulder
A staple of American barbecue, pork shoulder counts itself as one of the most forgiving of meats. If you smoke it for too long, the meat tends to dry out some but with enough BBQ sauce, you won’t need to worry. From a default, I usually serve my pork shoulder with no BBQ sauce as good BBQ doesn’t really need it but BBQ sauce is not faux pas and will bring more complexity to the dish.
Starting your fire
To start your fire you will need
Hickory Wood Chunks (read chunks, not chips)
What you will need to do is lay the charcoal and hickory into the coal pan of the smoker. Once placed, the chimney starter will be lit from the bottom to start the flame without lighter fluid. You can either use newspaper or Weber ignition cubes to get the fire started. The goal here is to get the coals in the chimney smoking and red hot so that you can dump them into the coal pile below. Avoiding lighter fluid is important here because the gasoline/lighter fluid smell will get into the food which will make for some unappetizing eats!
While the chimney is smoking, grab some pork shoulder and lightly apply yellow mustard. The mustard will work to hold the rub to the pork shoulder while it smokes to help the rub caramelize and give the pork shoulder nice bark. Once light mustard is applied, add on the rub on both sides of the pork shoulder
Once the chimney is on fire you will need to exercise caution to pick up the chimney starter, remove the grate and dump it onto the bed of coal and wood below.
By dumping the hot chimney coals to the pile below, it will ignite the rest of the coals without the use of lighter fluid and sustain itself for a prolonged period of time.
Next up fill your water pan with a watering can, this will help regulate temperature as well as generate additional smoke.
Once you have the smoker up and running you will have smoke from coal and wood that will run for a good 5-7 hour stretch before the temperature starts to diminish.
The trick with smoking meat is to try to keep the temperature low and slow. Too much heat and you will end up burning the meat. Not enough heat and the meat will not get past the stall and will not be as tender as you need it to be.
Smoking meat is somewhat of a marathon. The target temperature to hit with most meat is about 200 degrees F. At this point, meat tenderizes and reaches peak flavor. While it’s still possible to eat pork shoulder at 180 or even 190F, I’ve definitely seen that breaking past 200F will yield great results. Some people will go 215F but risk the meat drying out when smoked for that long. When smoking meat applying some apple cider with a spray bottle about 5 hours into the smoke. You can also wrap the pork shoulder in foil and spray the shoulder, this Texas Crutch will help speed up the process and shave off a few hours off the total smoke time.
After 6 hours the coals will die down, so at that point apple cider vinegar will be misted on the shoulder and you can either finish it up in the oven or load a new chimney or charcoal and keep going. It’s up to you if you want to wrap the pork shoulder or let it ride on the smoker. Since I was in a time crunch I decided to deploy the Texas Crutch and bring the pork shoulders to the finish line.
